Decentralized power bus system for supplying charging stations.
With podis®, you can create a flexible, economical, and expandable charging infrastructure for indoor parking garages. One flat cable can connect multiple charging stations with less effort!
THE BENEFITS TO YOU:
+ Complete more projects faster: Quicker installations, conversions
and expansions – no need for dismantling or stripping
+ Less mess & interruptions: Provide a better customer experience for building owners & residents
+ Future-proof: Additions & changes can be made at any point
+ Safe to operate: Maintenance-free penetration contacts
Greatly reduce the effort needed to make your building EV-ready. Install only as many chargers as needed and easily add additional chargers as demand grows. With the power bus system, the backbone of the system is established during the initial installation. Adding additional chargers is simply a matter of adding another connecting module. This saves considerable installation time compared to conventional pipe-and-wire installation and allows installers to complete more projects faster, and with less downtime for customers.
FUNCTION of SAFETY SWITCHES
The mechanical safety switches in the SIN series are suitable for the secure locking (guard locking) of safety doors until a hazardous machine process has ended.
The safety switches have two independent contact blocks which reflect the position of the actuator on the one hand and the
position of the guard locking on the other. The release of the entry or the shutdown of the machine in case of danger is done by the evaluation of the contact blocks by means of a suitable basic device of the safe RELAY series or one of the safety systems samos® or samos® PRO.
The safety switch on the guard is locked automatically when the actuator reaches its end position.
The guard is unlocked by applying a current to the internal electromagnets in the safety switch.
The safety switch on the safety guard is locked by energizing the internal electromagnet when the actuator reaches its end position.
If the internal electromagnet is de-energized, the guard control is unlocked and the guard can be opened
Integrated Safe Torque off is different from an emergency stop (E-stop). Depending on the standards and requirements for a particular application, it might be possible to use STO as part of an E-stop system. However, its main purpose is to be used in a dedicated safety control arrangement, designed to prevent foreseeable hazards from occurring. This paper summarizes the main differences between STO and e-stops, the requirements under the standards, the advantages of safe torque off, as well as the role of STO in motor starters.
Also known as Europa Terminal Strips, these terminal blocks come in divisible strips and are perfect for mounting electrical connections on a flat surface. Two versions are available, a regular version and a self-extinguishing version which complies with DIN 60335-1.
v. 0555.1 MC 12/22
The flare Power Relay is a general-purpose power relay for plug-in sockets.
35mm DIN rail,
Drop-in replacement for industry standard relays.
Other voltages on request.
The Wieland safety application manual showcases examples of safety circuits using our safety relays and controllers; also includes relevant Sistema calculations to help maintain the longevity of your machine’s operating lifecycle. It Covers EN ISO 12100, EN ISO 13849-1, and EN ISO 13849-2.
Update: Version 2 is now available with updated examples! In addition, new topics have been added, such as new aspects of the emergency stop, the use of electrical components with software without safety levels, Lockout/Tag-out (LOTO), and HRC.
Our rising cage PCB terminal 8142 ZP offers even more advantages compared to conventional products on the market. The smallest dimensions, highest safety at the connection torque, and the largest cross-section range as well as a high current carrying capacity up to 12 A make these terminals a universal solution.
Download 0552.1 03/22
Iboco NAB and T1 wiring duct in standard and narrow finger. Available for Canada only
The podis® MS 5HP is the first decentralized motor starter in IP65 / NEMA 12 with integrated Safe Torque Off.
Download 0838.1 CA 02/2022
